● Detection length and width settable: Length: from 0m to 50m; Width: 0~10m;
● Suitable for both on and off road applications;
● Handheld setup tool to adjust detection area freely.
Truck Parking Sensor System Radar Obstacle Avoidance Warning System for Mining Truck means a system to detect and inform the driver of the presence of objects in the close-proximity blind-spot front or rear or front & rear of the vehicle, if deemed necessary based on manufacturer strategy, warn the driver of a potential collision.
| Rated working voltage（V） | 12V /24V |
|---|---|
| Operating voltage range（V） | 9-36V |
| Working current | ＜200mA |
| Operating temperature range（℃） | -40 ~ +80℃ |
| Storage temperature range（℃） | -40 ~ +85℃ |
| Working frequency（GHz） | 76-77 |
| Antenna form | 2TX，4RX |
| Volume of display | ≥90dB@12V/10cm |
Unitech Object Detection Radar based on 77Ghz radar technology is specially designed to detect pedestrians, vehicles and objects in rear blind spots of commercial vehicle, effectively reducing accidents. It is able to identify motionless and moving objects, providing the driver with in-cab visual and audible warnings – alerting the operator whose attention can not be focused on all danger areas. Object Detection Radar works effectively in harsh and in poor visibility environments including darkness, heavy dust, smoke and fog.
♦ Radar Specifications
| ITEM | Parameter | ITEM | Parameter |
|---|---|---|---|
| Rated working voltage（V） | 12V /24V | Traceable target numberMAX | 31 |
| Operating voltage range（V） | 9-36V | Horizontal angle（°） | 110 @ -3dB |
| Working current | ＜200mA | Vertical angle（°） | 20 @ -3dB |
| Operating temperature range（℃） | -40 ~ +80℃ | Angle accuracy（°） | ±0.5 @ 40° |
| Storage temperature range（℃） | -40 ~ +85℃ | Angular resolution（°） | 15 |
| Working frequency（GHz） | 76-77G | Distance Accuracy（m） | 0.1 |
| Transmit power（dBm） | 12dBm | Distance Resolution（m） | 0.1 |
| Modulation mode | FMCW | Waterproof grade | IP67 |
| Antenna form | 2TX，4RX |
♦ Tracking Led Display Specifications
| ITEM | Parameter |
|---|---|
| Rated working voltage（V） | 12V/24V |
| Operating voltage range（V） | 9-32V |
| Working current | ＜500mA@12V |
| Storage temperature range（℃） | -40 ~ 85℃ |
| Operating temperature range（℃） | -40 ~ 80℃ |
| Volume | ≥90dB@12V/10cm |
♦ FEATURES:
● CAN communication: fast signal transmission and strong anti-interference ability;
● External output: trigger other warning device;
● Self-diagnosis alert to driver;
● Detection length and width settable: Length: from 0 to 50m; Width: 0~10m;
●Suitable for both on and off road applications;
● Excellent small blind zone to 20cm;
● High volume 90dB for noisy working environment;
● Flexible radar installation angle adjust;
● Identify motion or motionless objects;
● Famous brand Rogers high frequency PCB material: keep high consistency;
● Fashion sensor housing design, logo printing service available;
● Corrugated pipe wrapped cable much stronger and can protect cutting or damage effectively;
● Handheld setup tool to adjust detection distance and range, easy and convenient to operate.
♦ Applications
To be safety, follow Super Unitech Sensor
